Features
- Black Series finish: 304 stainless steel with a black finish, to match the other Black Series components.
- 60,000 BTU: 4 cast stainless steel burners at 15,000 BTU each with 4 stainless flame tamers.
- Rotisserie kit and cover included: with a ceramic infrared rear burner for the rotisserie.
- Double-lined hood: with mirror-finish edging and a built-in thermometer.
- Night lighting: two internal halogen lights; blue LED lights on a curved control panel with zinc alloy knobs.
- Full-size stainless drip tray: under a fully welded 304 stainless firebox.
Specifications
| Brand | Whistler Grills (formerly Bonfire) |
|---|---|
| Model | CBB4-B-LP (propane) / CBB4-B-NG (natural gas) |
| Finish | Black Series (black stainless steel) |
| Size | 34" W x 21" D grill head |
| Cut-out | 32 5/8" W x 20 1/16" D x 10 1/8" H |
| Main burners | 4 cast stainless steel, 15,000 BTU each (60,000 BTU) |
| Rear burner | Ceramic infrared (rotisserie) |
| Cooking area | 608 sq. in. total cooking area |
| Warming rack | 211 sq. in. |
| Cooking grates | 2, 304 stainless steel |
| Flame tamers | 4, 304 stainless steel |
| Lighting | 2 internal halogen lights; blue LED knob lights |
| Installation | Built-in |
| Shipping weight | 179.9 lb |
What's included
- 34" Black Series built-in grill head
- Rotisserie kit
- Grill cover
- Transformer for the lights
- LP regulator and hose (propane version)
Sold separately
- 4-burner insulating jacket for combustible islands
- 34" Modular Kitchen grill cabinet
- Black Series double side burner
- Black Series power burner
- Black Series doors and drawers, such as the double door and door and drawer combo
Installation planning
- Cut-out: 32 5/8" W x 20 1/16" D x 10 1/8" H. Whistler's cut-out drawing adds 3 1/2" behind the opening so the hood can open fully.
- The control panel sits flush against the front wall of the island. If the countertop overhangs the front wall, cut it back flush across the width of the control panel.
- Build it into a non-combustible enclosure (masonry, stone, steel). For an island framed with combustible materials, use the 4-burner insulating jacket.
- Leave openings in the island for drainage, replacement air and cross-ventilation. A propane tank stored in the island needs its own vented compartment, isolated from the grill.
- The lights run on the included transformer. Mount it at least 6" above the ground and plug it into a GFCI outlet (not included).
- Propane: use the supplied regulator and hose without alteration. Natural gas: no regulator is needed at the grill; connect it through a shut-off valve. Whistler strongly recommends professional installation and gas hookup.
- Rear burner: ceramic infrared, for rotisserie cooking with the hood closed. Don't run it with the main burners on, and take the warming rack out first.
Warranty
Whistler / Bonfire limited warranty for the original owner (not transferable), residential use in the US or Canada: limited lifetime on the cast stainless steel burners, stainless steel cooking grates and stainless steel housing; 3 years on the infrared rear burner, cast brass side burner, knobs, brass valves, drip pans, flame tamers and warming rack; 1 year on all component parts, the ignition system (batteries excluded) and electronics, including lights and thermometers. Under the lifetime and 3-year terms the part is repaired or replaced free, and the owner pays labor and freight. Harsh detergents or degreasers void the warranty.
