Features
- 5,000 watts from one 48-inch body: two 2,500-watt infrared elements for a wide spread of heat
- Half or full power: each element can be switched on its own with Bull's duplex stack switch (26202)
- Dual mount: wall or ceiling, by chains or brackets; flush into a ceiling with trim kit 26205
- Quiet infrared heat: no fan; it warms people and surfaces rather than the surrounding air
- Built for outdoor use: IPX4 rated and UL/CUL listed, made to stand up to rain, wind and sun
- Low running cost: Bull estimates about $0.80 an hour at $0.16 per kWh
- Serviceable: elements (26201), reflector (26210), guard (26211), end covers (26209) and brackets (26208) reorder by part number
Specifications
| Identification | |
|---|---|
| Brand | Bull Outdoor Products |
| Model | 26200 |
| Type | Electric infrared patio heater, dual mount (wall or ceiling) |
| Power and control | |
| Output | 5,000 W (2 x 2,500 W elements) |
| Voltage | 240 V; Bull makes other element voltages, so check the heater's label |
| Current | 20.8 A |
| Heat levels | Half or full power with the duplex stack switch (26202) |
| Smart control | Wi-Fi or Bluetooth switches through a single or dual contactor panel; not thermostat compatible |
| Running cost (Bull estimate) | About $0.80 per hour at $0.16 per kWh |
| Size and build | |
| Dimensions | 48" W x 8.19" D x 3.12" H |
| Weight | 13 lb |
| Element | Quartz tube infrared elements (26201), 2 |
| Outdoor rating | IPX4 |
| Listing | UL/CUL |
| Installation | |
| Mounting | Wall, aimed 30 to 60 degrees down; ceiling, tilted up to 30 degrees; flush ceiling mount with trim kit 26205 |
| Minimum mounting height | 6 ft (UL label) or 8 ft (UL/CUL label) |
| Clearances | 18" on all four sides; 12" to the ceiling when wall mounted, 6" when ceiling mounted; 36" in front; 6" behind the face |
| Wiring | Hard-wired; 1/2" conduit fittings; copper wire rated 90 degrees C / 194 degrees F |
| Warranty | 3 years (heater replacement parts) |
What's included
- Power Warm 48-inch heater (model 26200)
Bull does not publish an in-box list for this heater, and its manual describes the duplex stack switch (26202) as optional, so confirm the switch with us before ordering if you need it.
Sold separately
- Flush-mount trim kit (26205): recesses the heater into a flat ceiling
- Duplex stack switch (26202): runs each element on its own for half or full power
- Replacement heating element (26201): two per heater
- Mounting bracket set (26208), end cover set (26209), 48-inch body reflector (26210), grill guard (26211) and lead wire set (26212)
Installation planning
- Electrical: a licensed electrician must hard-wire the heater permanently, following the National Electrical Code and local codes for outdoor wiring, with a means of disconnection. Use 1/2" conduit fittings with rigid metallic, flexible or liquid-tight conduit, copper wire rated for 90 degrees C (194 degrees F), and wiring parts listed for outdoor use with at least an IPX4 rating. Do all assembly with the power off.
- Voltage: the supply must match the voltage on the heater's label. Heaters above 240 volts are for commercial use only.
- Wall mount: at least 18" from adjacent walls and 12" below the ceiling, aimed 30 to 60 degrees downward.
- Ceiling mount: at least 18" from adjacent walls and 6" from the ceiling, tilted no more than 30 degrees.
- Height: at least 6 ft above the floor if the label says UL listed, or 8 ft if it says UL/CUL listed.
- Clearances: keep 18" clear on all four sides and 36" directly in front, with brackets that hold the face at least 6" off the mounting surface. Keep cords, drapes, furniture and other combustibles at least 3 ft from the front and away from the sides and back, and never run it within 25 ft of flammable or explosive materials.
- Aim and position: mount it level with the quartz tubes horizontal (it can rotate on its horizontal axis to aim). Bull recommends about 45 degrees unless it is mounted above 12 ft, heating from the cold or windy side where you can, and not directly over tables or other objects that would absorb the heat. Mount it under a roof or cover when possible.
Care: Turn off the power and let the heater cool completely before any maintenance. Clean the end covers with isopropyl alcohol, mild detergent or warm water on a soft, scratch-free cloth, and use a stainless steel cleaner on oxidation, surface rust or discoloration; dry it fully and remove all water and cleaner before restoring power. To replace an element, switch off at the breaker, lift off the guard, remove both end covers, unhook the element clips and nuts, and fit the new quartz element, holding the ceramic end firmly while you snug the nut with an 11/32" wrench (a loose connection can short or shorten element life). Do not use the heater with a cracked or damaged element, never leave it running unattended, do not block it, and do not use it in place of forced-air or ductless heating.
Warranty
Bull's Power Warm manual (V2024.06.07) gives a 3-year limited warranty from the original purchase date against manufacturer defects in materials and workmanship. It covers manufactured replacement parts only, not labor, and excludes damage from negligence, misuse, improper installation or operation, unauthorized adjustments, cosmetic damage and harsh chemicals; using other makers' controls or accessories may void it. The manual asks you to register within 30 days of purchase at bullbbq.com/register.
Bull's warranty policy (v2026.10.29) lists heater replacement parts at 3 years. The policy covers the consumer who originally bought the product, at the original site of delivery or installation; it does not transfer to a later owner and does not cover rental, commercial or other non-residential use. Bull replaces the defective part or product free of charge at its discretion, but does not pay shipping on replacement parts or any labor. Damage from transport, storage, improper installation or use, failure to follow the instructions or perform maintenance, modifications, normal wear (including rust, corrosion, oxidation or discoloration) and outside causes is not covered.
Warranty claims go to Bull customer service at bullbbq.com/support or (800) 521-2855 (Monday to Friday, 8am to 5pm Eastern). Keep your receipt.
Manuals and documents
- Power Warm 48" heater Installation, Use and Care Manual, model 26200, V2024.06.07 (PDF)
- Power Warm heater spec sheet, item 26200, v2024.03.26 (PDF)
- Bull Power Warm premium infrared heater FAQ (PDF)
- Bull warranty policy, v2026.10.29 (PDF)
- Bull product page: Power Warm 48" 5000-Watt Infrared Dual Mount Outdoor Heater (26200)
